X- Ray Film Viewer

X- Ray Film Viewer
X- Ray Film Viewer
Product Code : NGS-XRFV
Product Description

X- Ray Film Viewer

  • Excellent material
  • Most advanced technology all over the world
  • Decrease eyes fatigue
  • Lamp house is long life , symmetrical , and energy saving
  • Excellent film- clamping set
  • Closer timer
  • Automatic induction function
  •  High frequency Medical LED Viewer
  • Brightness digitally adjustment
  •  2.5cm thick sensor / Film activation


Excellent material : Both screen and light route are made from a crypl products by japan Mitsubishi corporation,

which has better light transmittance than glass, and could use for long time , without distortion and colors charging.

Most advanced technology all over the world : A dopt updated TFT backlight , design only 25mm thickness for whole equipments by our professional technology , which is easy for install , and saving space with smart looking.

Decrease eyes fatigue : LED takes DC power circuit without twinkle, and have wide range of light adjustment (From 300 -4500 cd/m), So eyes won't feel tried even long time watching.

Lamp Housing is long life , Symmetrical , and energy saving : LED takes contant power , and could be used mare than 100,00 hours , which is 9-10 time than conventional flourescent lamp , and it has equidistant lamp house , which makes light more symmetrical , LTD also brings very low heat , which is energy saving (only 1/5 energy using compared with conventional film viewer)

Excellent film - clamping set: It takes self locking roll pin , replacing conventional sharpnel with roll pin, which is durable and easy used .

Closer timer : The MT series would shut off when used more than 1 hour , and could work a again only when you put new film in start it again .

Again Induction function : Section would start working only when film inserted inside , and other section won't work if they don't have films and the working section would shut off automatically when the film to ok off.

EV series Professional Medical film Viewer Parameter and specifications .

 Single- Section
 Double- Section
 Size LxHxW (mm)
 537x495x25 885x495x25 1240x495x25 1590x495x25
 Visible Size LxH (mm)
 370x422 751x422 1072x422 1432x422
 Light Source
  Light Color Temp 1000K  1000K  1000K  1000K
 Power Consumption
 20W 20W 60W 80W
 5.5kg 9 kg
 12.5kg 15kg
 H:3500cd/m' HT:300-4000cd/m' M:300-4000cd/m' MT:300-4000 cd/m'
